Fix Motorola Edge X30 5G Stuck on Boot Start screen logo

You can handle app updates without issues when your mobile has enough hardware space. Also, it can take the situation with limited hardware specs when you have optimized software. Motorola Edge X30 5G is a flagship mobile with 8/12GB of RAM and a Snapdragon 8-gen 1 processor. It can handle any apps or updates without issues daily. Since it also has a stock Android version, It can perform better than the custom skin UI. But for some reason, when Motorola Edge X30 5G is stuck on the boot logo after the massive update or root process, you can fix your mobile using one of the below methods. Always start from the primary method when you can’t select your mobile using the primary method, then you can move to other advanced techniques.

What is the Stuck on the Boot logo in Motorola Edge X30 5G?

OTA updates are, most of the time, flawless processes. But when the mobile begins to finish the first boot after the update, It is a nail-biting situation for most users. Because sometimes the boot can take a long time than usual. If the boot happens after a long time, it is excellent. But it is not a good sign when the boot takes more than 20 minutes and is stuck on the Motorola Edge X30 5G name logo. Even after your mobile is not booted into the regular screen, your mobile is stuck on the Moto Boot logo. You can wait for a few minutes. You don’t need to worry. We can start with simple methods to fix these issues. Always start with a simple process. Most of the time, the boot is stuck and set in simple ways.

Boot logo stuck can happen for various reasons and different situations. It can occur when you restart the mobile after the monthly security patch updates or major upgrades like Android 10. Due to overwriting existing codes in the OS and the process not going as expected, We have to deal with this kind of problem. When you face this issue, Don’t rush for firmware flash, You will lose user data. The Firmware flash should be your last choice, and We can recover your mobile using different methods. The stuck on the Moto Logo and The Mobile details screen logo can happen. For both screens, the following techniques will work.

How to Fix Motorola Edge X30 5G stuck on the Boot logo?

Our motto is as much as we can retrieve your mobile without losing data. But we must flash the full firmware to get your mobile back when we can’t. When you give more time than usual, and your mobile won’t boot into System OS, you can follow the below methods to fix your stuck Motorola Edge X30 5G on the Boot logo.

1. Long Press Power Button

Even if it is a simple method, you may wonder what technology can help here. Most of the time, all electronic devices will work after the power is off and on, and it will work most of the time. Long press your power button for 10 seconds, It will trigger your mobile’s power, and your mobile will shut down in a few seconds.

2. Boot into Safe Mode

Sometimes third-party apps may trigger the latest Version, and it may cause the stuck-in boot logo. Try to boot into Safe Mode by pressing Power Button for 30-60 seconds. Your mobile will boot into Safe mode. Try to Un-Install the recently installed app before the OTA process. Also, check the compatibility in Play Store. When installing apps other than Play Store, Uninstall them and try to boot again.

3. Reboot using recovery

This method will not affect your User data. It will only soft reset your mobile. You must press Volume Down+ Power Button on your mobile for 7-10 Seconds to boot into recovery mode. After that, it will kick you into recovery mode or directly boot into System OS. The response may vary depending on the mobile manufacturers. If you received a Recovery mode menu, use the Volume keys to navigate and the Power button to confirm the selection.

3.1 Stock Recovery method

If you didn’t use Rooted mobiles, you have Stock Recovery, provided by your official mobile manufacturer. If you have stock recovery, you can “Reboot.” Navigate to this option and confirm it using the power key button.

3.2 TWRP Recovery method

When using Rooted mobiles, you use Stock Recovery or TWRP custom recovery. If you have Stock Recovery, you can use the above process. When you install TWRP on your mobile, follow the steps below.

• The Keycombinations will boot your mobile into TWRP Recovery mode.

• On the Home screen, you can find the option “Boot.” Select the item; you will receive further options such as System, Power Off, Recovery, and Bootloader. Select “System.” Your mobile will boot into a Normal OS.

4. Using ADB Commands to Reboot, your boot logo stuck  Motorola Edge X30 5G Mobile

This process may work 50-60%. If you use Old Mid-range mobiles, the chances are less. But it will work when you have Flagship mobiles or New mobiles. The OS can still handle background commands. So, the ADB commands may work.

Steps

• Download the ADB drivers. Install it on your PC.

• Connect your mobile with a PC.

• Open a command prompt as Administrator and type below to check the ADB status.

• adb devices

• It should display the connected devices. If you didn’t get the mobile, restart the command prompt and Disconnect and Connect your mobile. If you are detected, type the below commands.

• adb reboot

• The order will reboot your mobile.

5. Drain the Battery Completely

When You can’t Power off or Restart your mobile, Let the battery drain completely. Because of the massive battery may take 1-3 days, depending on your mobile battery backup, to remain. You can proceed with other ways when you don’t have this much time and want to urge fix methods.

6. Wipe Cache Data Partition

When you perform, restart using recovery, and you can’t boot into OS again. We have another choice of the fix by Wiping the cache partition in this situation. It also will not affect user data. It will wipe only cache data. You must press Volume Down+ Power Button on your mobile for 7-10 Seconds. After that, it will boot you into the recovery mode or directly boot into System OS. The response may vary depending on the mobile manufacturers. If you received a Recovery mode menu, use the Volume keys to navigate and the Power button to confirm the selection. Remember to wipe only the cache partition, Not the Wipe Data/Factory Reset.

6.1 Stock Recovery method

• If you didn’t use Rooted mobiles, you have Stock Recovery, provided by your official mobile manufacturer.

• You can choose “Wipe & Reset if you have stock recovery.” Navigate to this option and confirm it using the power key button.

• Initially, try “Wipe Cache.”

• It will ask you to confirm the process. Select “Yes.”

• When a cache doesn’t work, Go for “Wipe User Data.”

• Most of the time, it will boot into OS after the wipe. When it returns to recovery, Select the Reboot system now.

6.2 TWRP Recovery method

When using Rooted mobiles, you use Stock Recovery or TWRP custom recovery. If you have Stock Recovery, you can use the above process. When you install TWRP on your mobile, follow the steps below.

• The Keycombinations will boot your mobile into TWRP Recovery mode.

• On the Home screen, you can find the option “Wipe.” Select the wipe option; you will receive further details. Select “Cache.” Don’t select the System, and it will wipe your OS. After selecting other choices, swipe to erase the data. When the process completes, return to home and boot into OS.

7. Disable Recently installed apps using ADB

You can often disable/remove the bloatware apps using Stock Android phones. If you are in Custom Skin OS, the chances of disabling the Bloatware apps are less. But, We can Disable the Apps using ADB without root. The methods may vary depending on the manufacturer. You have to find the particular Bloatware apps and disable them. I will give the overall idea about ADB steps and commands. But, the list of packages may vary depending on the manufacturers.

• Download the ADB drivers. Install it on your PC.

• Enable USB Debugging Mode and OEM Unlock; you’ll find these options in Settings >>> Developer options. If you didn’t see the developer options on your settings menu, go to about >>> build number. Then, about ten times regularly, click on the “Build Number” row to activate your device’s “Developer Option.”

• Connect your mobile with a PC and unlock your mobile (Screen Lock).

• Open a command prompt as Administrator and type below to check the ADB status.

• adb devices

• The above command will display some code for device detection. If you didn’t receive any response, Check with the USB Cable. If you get a response, move to the below commands.

• You can disable the apps based on their adb package name. You can find these package names using the below command.

• adb shell pm list packages

• Based on the title, you can exclude unwanted apps. After that, use the am force-stop and pm disables commands with the Application package name.

• You can enter the commands one by one, Or All commands and Hit Enter. You can get the application package name in Play Store URL. It will start with com.instagram.android like that.

• am force-stop package name(e.g: com.sprint.w.installer)

      pm disable-user package name

• Restart your mobile. Move to different methods when you are stuck on your Motorola Edge X30 5G Mobile boot logon.

8. Flash Boot. img file using ADB and Fastboot and Repair Boot logo stuck in Motorola Edge X30 5G

The boot image file is the main problem of being stuck in the boot logo. When we flash the particular boot image file, we can restore your mobile without losing data. But you should know what software version is already on the mobile. So you can always go with the latest boot image file. The following method may not work with EU carrier-locked mobiles.

• Download the ADB drivers. Install it on your PC.

• Download the Motorola Edge X30 5G firmware below and save it on your PC. Your Current OS and download version AP and CSC should be the Same.

• Motorola Edge X30 5G Android 12 ROM.

8.1 Extracting boot.img file

• Download 7Zip-ZS and Install it on your PC. Then, extract the files in the downloaded firmware using 7Zip-ZS. In those files, along with some data, you can see boot.img. You will get ROM files.

• Copy the boot.img to ADB Installed folder.

8.2 Flash boot.tar using ADB and Fastboot

• Connect your USB cable to your PC. To do this, press and hold Volume Down+ Power Buttons and Connect Your Mobile To your PC via USB Cable; after Moto Logo Appear, Release all keys. Then, enter Fastboot mode. Switch off your device.

• Press the Volume Up button to continue when you see the warning message.

• Connect the Motorola Edge X30 5G Mobile to the USB cable computer.

• Launch the fastboot on your computer. Next, open a Command prompt on your PC and type the below command.

• fastboot devices

• It should display the connected devices. If you didn’t get the device, restart the command prompt, disconnect, and Connect your Motorola Edge X30 5G. If you are detected, type the below command and hit Enter.

• fastboot flash boot boot.img


• After completing the process, Press the Volume Down+ Power button to exit Fastboot mode. Immediately Press Volume Up + Power buttons when the screen goes off to boot into Recovery mode.

• After entering Stock recovery mode, Go to Wipe Data/Factory Reset and Select Yes to wipe data. It will erase the saved data on your device. Don’t Boot into OS; read below Boot stages before booting.

9. Flash Complete Firmware using RSD Lite

We are going full flash firmware in your boot logo stuck Motorola Edge X30 5G Mobile in this method. It is a Data loss process, and you can use it when you have no choice and none of the above methods work for you. Refer- Motorola Edge X30 5G Firmware.

9.1 Flash Motorola Edge X30 5G Android 10 ROM using RSD Lite Tool

• Download the Motorola USB driver and install it on your PC.

• We are using third-party software flashing. Download RSD Lite and install this also on your PC.

• Connect Your Mobile To the PC Using USB Cable.

• Switch off Your Mobile and Enter Fastboot Mode->Press and Hold Volume Down+ Power Button.

• Release all the keys when you enter Fastboot mode.

• Now Launch RSD Lite. Select Your Downloaded Firmware Using this “…” The symbol in the RSD Lite.

• It Will Asks For the Unzip. Just Select Uncompress.

• Check With Your Mobile Details.

• Now go to Your Mobile, Press Volume Down Key, And Select AP Fastboot. Make Sure that the USB Connected Message is Displayed (Transfer Mode: USB Connected).

• Now Select the Start in the RSD Lite. Wait For The Process to Complete; your Mobile Will Reboot After the Process Completion.

Wrap Up

Even if the software updates process looks simple, 1-5% of people always face making OTA updates. That’s why we suggest you always back up before updating your mobile. Always use cloud photo backup services like Google Photos. Compared with other mobile manufacturers, with the help of Motorola’s available tools, we can fix your Motorola Edge X30 5G stuck on the boot logo.

If you face freeze and unresponsive issues on your mobile, You should try different methods than those mentioned above. It is wise to give some time for the first boot after the update. The first boot may take longer based on your available storage and app size. When you are confident that the mobile is stuck and given enough time for initialization, you can follow the above steps to fix your mobile. Comment below when you try different methods than above, and those techniques help you. We try to add if those methods work for everyone.
