Root Samsung Galaxy S20 FE 4G/5G SM-G780F/G781B/N Android 12 using TWRP and Magisk

The reason for rooting changed from time to time. In the early stages, People begin to root their mobile to enhance their memory and performance. But, In recent days, most mobiles come with powerful specs. So, Only Root app users still prefer Rooting. Samsung Galaxy S20 FE has powerful specs and can handle any app or update without issues. But when you are a regular Root apps user or Developer, you can Root your Samsung Galaxy S20 FE Android 12 using the below method. Since We are using TWRP in this process, You can install any custom ROMs or apps.

Compared with standard other root methods, this method has additional steps. Since it doesn’t use a custom recovery, You can’t install custom ROMs. But, It is enough to run most of the root apps. So, You should care a little bit when you do the process.

After root, you will lose official updates and have to update your mobile manually. So, Before proceeding with the process, you should know why you need to do it. If you are a regular user, you can try some alternatives for your purpose that don’t require root. When you are a regular root apps user and Developer, you can follow the below guide to achieve root on your mobile.

Should you need to Root your Samsung Galaxy S20 FE 4G/5G SM-G780F/G781B/N Android 12 version?

It would be best if you had a strong reason for rooting. Samsung Galaxy S20 FE already got One UI 4.1 based on Android 12 and is optimized. You have More than Enough 6-8 GB RAM to use daily apps without lag for years. I Know; that RAM may look insufficient because of Samsung’s Heavily customized OS. But, Trust me, One UI is far better than other Custom Skin OS. You can use this device without lag for years until Samsung mess with some Bloatware. But beyond this not go reasons you are addicted to some root apps, or you are a frequent user of some Custom OS, you can proceed further. But if you want to root because everybody is doing it, I advise you, don’t root If you don’t have any experience. For regular users, It can become a Nightmare.

How to Root Samsung Galaxy S20 FE 4G/5G SM-G780F/G781B/N Android 12 One UI 4.1

Thanks to the Developer- afaneh92, for the Root method and topjohnwu – this genius is the one who discovered and maintained Magisk. Samsung Galaxy S20 FE variants come with a flexible bootloader in some regions. We can easily root the smartphone, and the device can also accept installing TWRP recovery or any other custom recovery file/app. Don’t try with Snapdragon US Variants like Verizon devices, which come with a locked Bootloader.

But In the below method, we will Root this device using Magisk. You can install Official TWRP using the official app when it is released. TWRP recovery is a custom recovery file we must install on your devices to root them successfully. This article explained the easiest method to follow and install Magisk on Samsung Galaxy S20 FE. However, the tool required for rooting this device is the Magisk App.

You can flash TWRP once it is available. With the help of TWRP Recovery, you can quickly flash the Custom ROMs into your Samsung Galaxy S20 FE. Before sharing the tutorial, you may want to know that you can easily install any root apps with the Magisk on your device. Does it seem complicated? Relax; We will explain everything briefly in bullets.

Things to check out for;

• Check your device model number.

• You should back up your current files and data- Full Data Loss Process (save them on external storage).

• Install Latest Magisk Manager.

• Make sure your device battery is above 50%

• You cannot use Samsung Pay, Secured folder, or some official Samsung apps.

• You can’t update your firmware; to get new firmware, you must follow the below steps with the latest firmware.

• Read the full tutorial before the process.

1. Unlock Bootloader

• Enable USB Debugging Mode and OEM Unlock on your mobile. To do this, go to settings >>> about >>> Tap on the “Build Number” 7-10 times consistently to enable “Developer Options,” then go to the “Developer Options” and enable USB Debugging Mode and OEM Unlock. There is no complicated process in the Samsung Galaxy S20 FE.

• Switch off your device. Enter into Download Mode-> Volume Down+ Power Button and Connect your mobile with your PC using a USB Cable. When the Download mode warning screen Appears, Press the Volume Up button to unlock the Bootloader.

• The above process will wipe your user data. After setup your device, Please recheck the OEM Unlock in the settings, and sometimes It Will Lock Again.

2. Download Necessary files

• Download and install the Samsung USB driver to your computer system.

• Install ODIN on your PC. Select the above Oreo version in the ODIN list. Also, download the ODIN software.

• Download Samsung Galaxy S20 FE Android 12 Firmware and save it on your PC. Your Current OS and download version AP and CSC should be the Same.

• You can use Phone Info to know your firmware version.

• Download 7Zip-ZS and LZ4, and Install both on your PC. Extract the files in downloaded firmware using 7Zip-ZS. You will get four files.

• Download twrp-3-6-2_11-7-s20-fe-a12.tar and copy it to your PC. And Download multidisabler-Samsung-2.6a.zip and copy this file to your mobile external storage.

3. Flash Vbmeta Disabled using ODIN

• Download Vbmeta Disabled.tar.

• Unlock your screen lock. There should be no fingerprint, PIN Lock, or Wipe. Set No lock in the settings.

• Switch off your Mobile. Enter into Download mode->Volume Down+ Volume Up Buttons and Connect Your Mobile To PC via USB Cable; after Samsung Logo Appear, Release all keys.

• After entering into Download Mode, it will say Warning; press the Volume Up button to continue.

• Launch Odin Application.

• It Will Show the message added.

• If you did not get this message, Repeat the above steps.

• After Getting Added Message Select, USERDATA Button, then Browse for the Vbmeta Disabled file, and select it. Un-Tick the Auto-Reboot.

• Press Start and wait for the tasks to complete. After completing the process, Press the Volume Down+ Power button to exit Download mode. When the screen goes off, Immediately Press the Volume Up+ Power buttons to boot into Recovery mode.

• After entering Stock recovery mode, Go to Wipe Data/Factory Reset and Select Yes to wipe data. It will erase your saved data on your device. Even if we flash the Vbmeta disabled, It is safe to flash the full firmware along with the Vbmeta Disabled.

4. Flash Samsung Galaxy S20 FE firmware files along with Vbmeta Disabled using ODIN

• Switch off your Mobile. Enter into Download mode->Volume Down+ Volume Up Buttons and Connect Your Mobile To PC via USB Cable; after Samsung Logo Appear, Release all keys.

• After entering into Download Mode, it will say Warning; press the Volume Up button to continue.

• Launch Odin Application.

• It Will Show the message added.

• If you did not get this message, Repeat the above steps.

• We have already downloaded the firmware files. When you extract the files, You will get five files.

• After Getting Added Message on ODIN, select the AP button and the AP file from firmware. The same goes for other files too. But when you choose CSC, You have to select the Home_CSC file. In the USERDATA Button, browse for the Vbmeta Disabled file and fix it. So, We have five files selected for five tabs. Un-Tick the Auto-Reboot.

• Press Start and wait for the tasks to complete. After completing the process, Press the Volume Down+ Power button to exit Download mode.

5. Flash TWRP File using ODIN

• Connect your USB cable with your PC. Switch off your device. Then, enter into Download mode. Press and hold down the Volume Down+ Power buttons and connect your USB Cable.

• Press the Volume Up button to continue when you see the warning message.

• Connect the Samsung Galaxy S20 FE mobile to the computer via USB cable.

• Launch the Odin app on your computer. If this app detects the device (Odin), it will show you a message that reads – added!!!

However, you won’t see this message if the device is not correctly connected to the PC. So, you have to check the USB cable to see if it is reasonable and reconnect the device.

• After connecting the Samsung device, click the PDA/PA button to browse/search and get the TWRP from where you saved it on your PC. Also, navigate to “options” and Un-tick the Auto-Reboot.

• Click on “Start”

• Once the file is loaded into the device, Don’t reboot your device.

• Kudos, you have just Installed the TWRP on your Samsung Galaxy S20 FE. If you installed TWRP, Don’t turn on your mobile. Immediately, move to Magisk Installation steps. You can do this by Pressing Volume Down+Power to exit download mode, then Pressing Volume Up+ Power to enter recovery mode.

6. Install Magisk and Multi Disabler in your Samsung Galaxy S20 FE using TWRP

• Boot it into recovery mode->Volume Up + Power Button.

• Now it Will Boot into TWRP Recovery Mode.

• Select Wipe->Advance Wipe->Select Cache and User Data.

• Return to Home of TWRP and select Install.

• Select multidisabler-Samsung-2.6a.zip.

• Return to Home of TWRP and select Install.

• Select the Magisk.zip file.

• You should Install them One by One. Don’t add more zips feature in TWRP. After the Installation, Reboot Your Mobile.
